HI-PE Plus Enhanced Walk-Through Multi-Zone Metal Detector

Quality

• Continuous self diagnostic system
• Proven reliability
• No periodic re-calibration and preventive maintenance required
• No scheduled maintenance
• Fully digital design

Gate structure

• State-of-the-art, robust and washable panels
• Protected against aging, weather and wear

Central control unit

• Ergonomic and robust design
• High visibility alphanumeric display and programming keyboard
• Made of advanced plastics or stainless steel and anti-vandalism construction (option)
• Access to the front panel protected by hardware key and 3 levels of passwords

Alarm signaling

• Visual signals
  • Multi-zone display bar for “height on person” localization
  • 4 light bars with selectable entry/exit and pacing indication
  • Green and red metering signals proportional to the mass of the detected target
• Audio signals
  • 10 selectable continuous and pulsed tone plus 34 special tones
  • 10 selectable sound intensities ranging from 0 to 90 dbA at 1m

Type of signaling

• Visual: Fixed or proportional to the mass in transit – visible from 6m under lighting of 4000lux
• Visual zone indication: 60 distinct zones (20 vertical x 3 lateral) entry and exit side

Programming

• Up to 50 built-in Security Programs
• Remote via Infrared Remote Control Unit, BT wireless communicationTM or Ethernet 10/100 base T (option) interface
• Security level
  • International Standard (IS) command
  • Chip card
• Local by Control Unit alphanumeric display and keyboard
• Programming and chip card access protected by user and super-user passwords

Operational features

• High discrimination and transit flow rates five or more times greater than other metal detection systems
• Quick reset time as short as 0.2 seconds for high throughput rate
• Very high detection speed (up to 15 m/sec.)
• Built-in operational functional verification
• One-touch key reading of inbound, outbound and Security Level Data

Installation data

• Automatic synchronisation between two or more metal detectors with distance of down to 5 cm without the use of external cables
• Automatic Installation function (OTS)

Environmental data

• Power supply: 100…277V~ ±10%, 47…63Hz, 40 VA typical consumption
• Operating temperature: -20°C to +65°C (-37°C to +70°C upon request)
• Storage temperature: -37°C to +70°C
• Relative humidity: 0 to 95% (without condensation)

Certification and compliance

• Complies with the applicable Standards for Law Enforcement and Correctional Facilities
• Compliant with and certified to the applicable Standards for Enhanced Metal Detectors (EMD)
• Compliant with the applicable electromagnetic Standards on Human Exposure and Pacemaker Safety
• Compliant with applicable International Standards for electrical safety and EMC
• Harmless to magnetic media (CD, tapes, etc.)

Comprehensive support

• CEIA provides full operational and technical training support by certified personnel either at CEIA facility or at customer location
