ZKTeco developed PA22 with Computer Vision Technology that included 3-in-1 contactless palm recognition. This contactless palm recognition terminal, powered by ARMATURA, can perform biometric authentication with a user’s palm vein, palm print, and the shape of palm at the same time once the sensor detects a hand presented.
- Display: 2.4-inch TFT Color Display (320*240)
- Hardware: 1.0GHZ Dual Core ARM Processor,Memory 256MB Flash,256MB RAM
- Authentication Method: Palm Recognition, RFID Card, Pin Code
- Palm Capacity: 1,000 (1:N)
- Card Capacity: 5,000
- Transaction Capacity: 50,000
- Palm Recognition Time: ≤0.4 seconds per palm
- Palm Recognition Distance: 18cm – 35cm(7″ – 13.7″)
- Communication
TCP/IP, RS485, Wiegand, USB, WiFi(Optional)
- Standard Functions
TCP/IP, USB Host, T9 input, 14 Digit User ID, Record Query, Webserver, Magnetic
Tamper Detection System, Live Palm Detection - Optional Functions
IC Card, Wi-Fi
- Support Card Type
ID Card (13.56 MHz frequency)
- Algorithms
Armatura PALM 12.0
- Power
12V DC, 3A
- Operating Temperature
-5°C to 45°C
- Operating Humidity
10 – 95% RH (Non-condensing)
- Operating Lighting Environment
≤2000lux
- Dimension
(L*W*H)：159.8 * 80.7 * 41(mm)
- Certifications
ISO 9001, ISO 14001, CE, FCC, RoHS
- Supported Software
ZKBioAccess IVS
