- Mã sản phẩmRG-NBS5200-48GT4XS
- Thương hiệuRuijie
- Xuất xứChina
- Giá:Liên hệ
Ruijie Networks là một trong 4 nhà sản xuất thiết bị mạng – wifi cấp doanh nghiệp (Enterprise) lớn nhất thế giới (Ruijie, Cisco, HP, Huawei,…). Các sản phẩm cấp doanh nghiệp được kiểm tra và chứng nhận bởi công ty Tolly (USA).
RG-NBS5200-48GT4XS là một trong những sản phẩm thuộc bộ sưu tập sản phẩm của Ruijie, được phân phối bởi Công ty CPCN Phúc Bình. Với thiết kế tinh tế kết hợp cùng những tính năng nổi bật, phù hợp sử dụng cho khách sạn, nhà máy, cửa hàng, văn phòng vừa & nhỏ.
Responding to the call for energy saving, RG-NBS5100&5200 series switches adopt a variety of energy-saving design concepts after in-depth research and exploration on the problems of traditional switches in terms of noise and energy consumption, solving the problem of excessive noise when deployed in the office environment and the high energy consumption problem caused by large-scale deployment of access equipment.
RG-NBS5100&5200 series switches adopt the next-generation hardware architecture as well as advanced energy-saving circuit design and components to save energy for users while reducing noise pollution.
With Energy-Efficient Ethernet (EEE), if the port of RG-NBS5100&5200 is idle for a continuous period of time, the system will set the port to energy-saving mode. When there is a need of packet transmission, RG-NBS5100&5200 will wake up the port to resume service via signals sent on regular intervals to achieve energy saving.
Surge Protection Ensuring Product Stability
The 6KV surge protection of the port reduces the probability of being damaged by surges and improves the customer’s network stability.
Auto-networking for Switches Allowing One-step Project Management
RG-NBS5100&5200 can obtain the IP address automatically from the gateway and connect to the external network without configuration. It also supports auto-networking for switches. Users can scan the QR code of any switch in the network using the mobile app to automatically add all switches in the network to the project.
Ruijie Cloud App/ Ruijie Cloud Platform Remote Management
RG-NBS5100&5200 not only supports web interface management, but also supports mobile app and Ruijie Cloud platform remote management. Users can view the network status, modify the configuration, and troubleshoot at home.
24 10/100/1000Base-T ports, 4 SFP+ 10GBase-X ports, fixed single AC power supply
48 10/100/1000Base-T ports, 4 SFP+ 10GBase-X ports, fixed single AC power supply
24 SFP ports (SFP: 100/1000M ports), 8 combo 10/100/1000Base-T ports, 4 SFP+ 10GBase-X ports
24 10/100/1000Base-T ports, 4 SFP 1000Base-X ports, fixed single AC power supply
48 10/100/1000Base-T ports, 4 SFP 1000Base-X ports, fixed single AC power supply
Packet forwarding rate
Support static MAC address, MAC address filtering
MAC address table size
Number of VLANs
Layer 3 aggregation ports
Support static routing
IP standard ACL
MAC extended ACL
IP extended ACL
Port ACL for Layer 2 ports (physical port / AP)
Port-based speed limit (ingress/egress)
Web management, Ruijie Cloud platform or Ruijie Cloud app management
Operating temperature: 0 ℃ ~ 50 ℃
Storage temperature: -40 ℃ ~ 70 ℃
Operating humidity: 10% ~ 90% RH
Storage humidity: 5% ~ 90% RH
